Gardner Bender GDT-3200 Digital Multimeter, 7 Funct, 8 Range, Tests AC/DC Volt, Resist, Diode, Continuity, Temp and Battery, Auto Ranging

Part # GDT-3200

When you contemplate adding a multi-meter to your toolbox this Gardner Bender auto-ranging unit makes the decision easy. Equipped with an easy-to-read More...

WHERE TO BUY
Out of Package Height (in) 5.75
Out of Package Width (in) 1
Out of Package Length/Depth (in) 3.25
Each in Package Height (in) * 9.25
Each in Package Width (in) * 3.35
Each in Package Length/Depth (in) * 4.72
Each in Package Weight (lbs) * 0.9313
Inner Pack Weight (lbs) * 4.13
RoHS Compliant (Restriction of Hazardous Substances Directive) ° Yes - Compliant
Color Red

When you contemplate adding a multi-meter to your toolbox this Gardner Bender auto-ranging unit makes the decision easy. Equipped with an easy-to-read 3.5 inch backlit LCD digital display and magnetic holding strap making this tester ideal for automotive, appliance, circuit breaker, and other "hands-free" applications. In addition the multimeter features rubber housing to promote a steadfast comfortable grip while wrap-around lead holders keep leads at the ready. Snap-in probes spaced to fit a standard outlet provide quick and easy testing with one hand. Engineered with seven testing functions; AC Voltage to 500V, DC Voltage to 600V, Resistance to 20 meg Ohms, Diode, Continuity (includes audible indication), Temperature Probe (32 to 482 degrees F) and Battery Testing for 1.5 V batteries. The 8 position auto-ranging smooth rotary dial helps achieve precise and accurate readings and the low battery indicator with auto-off function helps prolong the battery life. The durable housing with a rubber boot is drop resistant to 6 ft and crush rated to 150 lbs. Tight and secure input jacks keep the included 26" test leads fixed firmly in place during testing. The unit comes pre-packaged with leads and includes a 1 year warranty. The tester is rated CAT III 600V and conforms to UL 61010-1 standards and certified to CAN/CSA C22.2. (Requires 2 AA batteries - not included)

  • 8 Position, smooth rotary dial
  • Data hold feature captures the reading on the display
  • Durable, drop resistant housing
  • Backlit 2000 count digital display
  • Replaceable 26" test leads
  • Protective rubber boot with test lead holders and tilt-out stand
  • Snap in leads spaced to fit standard outlets
  • Compact design for easy use, storage, and transportation
  • Conforms to UL 61010-1 standards and certified to CAN/CSA C22.2

Warranty One Year
Includes Tester, leads, operating instructions
